Guillotine Paper Cutting Machine

Guillotine Paper Cutting Machine

Guillotine Paper Cutting Machine Variant contains everything needed for Accurate Paper Cutting. Auto measurement devices, Programmable Devices, Air Cushion Stainless Steel Bed, Established instinctive administrator direction, Hydraulic Pressure System, huge touch screen, and cycle perception.

Electromagnetic handle system for most outrageous efficiency and least help. The Guillotine Paper Cutting Machine is Equipped with Programmable Adjustable back-measure for exact parallelism with sharp edge. The fast-cutting stroke is incredibly exact, to the sharp edge carrier guides. This machine is moving along as arranged and definite with its solid arrangement. The Hydraulic Pressing is given prosperity to the director of the Guillotine Paper Cutting Machine. Security Sensor cells protect the well-being of the administrator against any sort of Accident.

The Guillotine Paper Cutting Machine has an innovative guillotine trimmer with an amazing sizing range. It is a robust solution specifically designed for high-volume cutting operations at one single time. It offers extraordinary precision and efficiency to our productive operations. It is built up of a durable cast-iron frame and hard chromed air table with a fluent knife bar which makes all the cutting operations hassle-free.

Features

  • Box-type design of elements and excessive grade material of principal components gives rigidity & long existence to the device
  • Specially designed electromagnetic take hold of & brake unit guarantees brief action of knife carrier
  • The latest hydraulic power % unit with double strain cylinder for clean hydraulic transmission
  • Safety Sensor electric powered safety device in the front of slicing knife
  •  AC power system for easy and uniform movement of the back gauge
  • The returned gauge is pushed using dual pace motor with a separate E.M. Seize brake unit mounted on its lead screw
  • Slot last belt is supplied on the main bed of the device
  • Dust unfastened feather touch keyboard for clean operation of programmed unit
  • Program managed air cushion table for clean movement of cumbersome stock
  • Program execution is viable both in semi or computerized mode.
  • Technical Specification

 Model

33

37

43

45

55

 Cutting Width

33"(835mm)

37" (900mm)

43" (1060mm)

45" (1150mm)

55"(1300mm)

 Clamp Opening

120 mm (4.5”)

120 mm (4.5”)

130 mm (5.0”)

130 mm (5.0”)

130 mm (5.0”)

 Minimum Cut without False Clamp

 25 mm (1”)

 25 mm (1”)

 25 mm (1”)

 25 mm (1”)

25 mm (1”)

 Speed of Mechanical Cut/Minute

 50

 50

45

40

40

 Blade Thickness

12.7 mm (½”)

12.7 mm (½”)

 12.7 mm (½”)

 12.7 mm (½”)

12.7 mm (½”)

 Power required

5 H.P.

7 H.P.

7 H.P.

7 H.P.

10 HP
